Material
Stainless Steel
Connection
Flanged
Seat
TFM 1600
Pressure rating
CL150
  • Stainless Steel Ball Valve - Flanged ANSI 150 - ISO Top
1 1
View datasheet

This datasheet is being prepared for the website. If you need a copy in the meantime, complete the form below and our team will send it over.

Product features

ISO 5211 for Direct Mount. Flanged ANSI 150, Full Bore, Stainless Steel Body, Ball & Stem, TFM 1600 Seats, Anti-blowout Stem, Anti-static Device. Firesafe Certified ½" to 4", 6" & 8" Firesafe Design.

  • Connection: Flanged
  • Fitting: ANSI 150
  • Material: Stainless Steel
  • Seat Material: TFM 1600
  • Mounting: ISO 5211 | Direct Mount
  • Pressure Rating: CL150
  • Temperature: -29°C to 200°C

Product specification

General Material Stainless Steel
Body Material Stainless Steel
Seat Material TFM 1600
Connection Type Flanged
Fitting ANSI 150
Mounting Standard ISO 5211 | Direct Mount
Pressure Rating CL150
Temperature Range -29.0°C to 200.0°C
Manufacturer Valtec
Category Code BV1
Product Family 1485

Stainless Steel Ball Valve - Flanged ANSI 150 - ISO Top

Available sizes: ½"–8"

SKU: Select a size

Select a size for availability

Stainless Steel Ball Valve - Flanged ANSI 150 - ISO Top

From

£66.48 ex VAT

(subject to size)

Same-day dispatch before 3PM on qualifying items.

Project pricing available on request

Technical selection support available

Pressure and compliance guidance

Select a size

Size
Price
Stock
Qty
1/2"
£66.48 ex VAT
Available
3/4"
£81.90 ex VAT
Available
1"
£120.43 ex VAT
Available
1 1/2"
£214.62 ex VAT
Available
2"
£302.64 ex VAT
Available
3"
£632.70 ex VAT
Available
4"
£924.91 ex VAT
Available
6"
£2,124.59 ex VAT
Available
8"
£3,241.76 ex VAT
Available
Request a project quote

For project, repeat or volume orders, use Request a Project Quote and send us your requirements.
